Spesifikasi :
- Capacity of 8K-bit EEPROM
- Divided into 16 sectors, each sector is 4 block, each block of 16 bytes, to block access units
- Each sector has a separate set of passwords and access control
- Each card has a unique serial number for 32 anti-collision mechanism to support multi-card operation
- Power supply comes with the antenna contains encrypted control logic and communication logic circuit
- Data retention period of 10 years, can be rewritten 100,000 times, read unlimited
- The working temperature: -20 ℃ to 50 ° C (90%) temperature of PET material encapsulated M1 card, temperatures up to 100 ° C.
- Operating frequency: 13.56MHZ
- Communication rate: 106KBPS
- Read Distance: less than 10 mm (the reader)
